CBW 2000L mud pumps for drilling rigs HDD machine

Whatsapp: 0086 18274950733

Request a quote now

Answer any question about the products for you.

CBW 2000L triplex mud pumps all named as HDD mud pumps, Diesel engine mud pump, Mud pumps for drilling rigs, which is a horizontal triplex reciprocating single-acting plunger drilling pumps, driven by diesel engine, equipment with automatic shift gearbox, wireless remote control.

It can be used for the purposes, such as grouting, mine drainage and long-distance water delivery. This plunger mud pump has five kinds of flow and pressure.

Its main role in drilling process is to supply flushing fluid to the drilling hole to circulate in the drilling hole, so as to carry cuttings back to the ground, keep the bottom of the hole clean, protect the wall of the hole from collapse, and cool and lubricate the drill bit and drilling tool.

ZLCONN CBW 2000L mud pumps adopting advanced structure and new materials. With following features: Reliable capability, long service life of the wearing parts, small volume, good decomposability and convenient movement etc.

2000L Mud Pumps
2000L Mud Pumps

Main Features:

1.  With Cummins diesel engine;

2.  Wireless remote control, improving efficiency;

3.  Easy operation, reliable performance;

4.  Good disassembly, easy maintenance and relocation.

Technical Parameters and Specifications of CBW 2000L Mud pumps :

TypeHorizontal Triplex Reciprocating Single Acting Plunger Mud Pump
Stroke (mm)150
Cyclinder Diameter (mm)155
Flow (L/min)2000      1500      1140      760      500
Pressure (Mpa)  4           5.4         7            9        10.5
Input Speed (r/min)162
Dimensions (mm)4800*2100*2100
Weight (kg)6050
Diesel ModelQSB8.3-C260
Diesel Engine Power (KW)194
Rated Speed (r/min)1700
